Webinars

View our list of past webinars covering various different topics and functionalities of LogoPress. Any upcoming webinars can be found under the Events panel on the side of our website.

▶

Webinar – Live LogoPress DieDesign Demonstration Creating a Complex Strip Layout, 3D Modeling of the Die, Insert BOM, 2D Detail Drawings, Run DIE DEBUGGER™, etc.

(1:04:21) MetalForming magazine and Accurate Die Design Software present—from start to finish—a live and thorough demonstration of the LogoPress DieDesign software package. Starting with only a complex, “dumb” imported part, a nearly complete strip layout is created including cutting punches and form punches. Designing around this strip layout, a substantial portion of the die assembly is created, 2D detail drawing functionality is demonstrated, and the computer-generated Bill of Materials (BOM) for the die is inserted into a 2D drawing. Play video

▶

Webinar - Live Demonstration of Forming Simulation and Automatic Blank Development Using LogoPress ProgSim

(1:01:35) This live demonstration of ProgSim forming simulation software is performed on a previously created LogoPress strip layout. These same cutting punches and forming punches are automatically recognized by ProgSim during the setup process, and ultimately get used by ProgSim to cut and form the net flat blank. This webinar showcases ProgSim's functions of formability results, displaying detailed press forces, showing springback, and the ability to automatically optimize the cutting punch geometry to fit the part withing tolerance of the CAD model. Play video

Video Categories

Open a category below to see various videos covering each topic.

LogoPress ProgSim

Forming simulation of dies, including stress, strain, splitting, wrinkles, springback, thickness - as well as automatic blank prediction. Cutting punch geometry is optimized with lines and arcs. A virtual tryout press to iterate designs for you.

Dozens of 1 Minute LogoPress Discovery Videos

Learn more about various aspects of LogoPress in about a minute. This area includes videos on the 2D drawings tools LogoPress Hole Tables and LogoPress Smart Ordinate Dimensioning. Other videos include the creation of a Wire EDM Burn Block, 2D and 3D Form Punches, Punch Mismatches, adding Wire EDM Holes, Engineering Changes, etc.

Real Time Die Designs

Various die designs are recorded in real time, including a very complete progressive die design done in just over 5 hours, including all 2D drawings, 2 engineering changes and interference detection. Also included are a Fineblank die, a Compound die, a Two station hand transfer die and a Lamination die design that produces a Stator and a Rotor.

LogoPress DIE DEBUGGER™ (Motion simulation of dies, including dynamic interference detection)

LogoPress DIE DEBUGGER helps to make the die designer a much better designer by helping him or her to catch their mistakes before the die design gets out onto the shop floor. Of course it is also a great visual tool for teaching people about die design as well as making design reviews much more efficient and meaningful.

Strip Layouts Created Using LogoPress

Accelerate the strip layout and quoting process with LogoPress. Multiple examples ranging from electrical terminals to round draws.

Unbend Dirty Parts, Flatten Complex Double-Curved Parts

LogoPress Flatten provides the user with two powerful tools for flattening parts. Unbending by Steps can unbend dirty imported parts (without any special preparation), calculating the correct K-factor for the bend. Finite Element Analysis of complex formed parts can be performed using the Blank command, generating a flat blank, as well as thinning,…

Free LogoPress Design Manager (123GO)

LogoPress Design Manager (123GO) is for those companies that need to work with a LogoPress die design in SOLIDWORKS, but don’t have a LogoPress product installed on their computer. It is a FREE SOLIDWORKS Certified Gold add-in that will cause SOLIDWORKS to automatically recognize and properly rebuild LogoPress-specific features, while also…
